Key facts
- Brand
- Siemens
- Model
- 611
- Category
- Automation control Equipment
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2026-09-29
Start here
Siemens SIMODRIVE 611 Drive Converters Configuration Manual
The SIMODRIVE 611 Configuration Manual provides detailed guidance for OEMs to configure, construct, and commission drive converter systems. It includes chapters on system configuration, motor selection, control units, power modules, infeed modules, line supply connection, and important circuit information.
Safety and compliance are emphasized throughout, with warnings about high‑voltage hazards, requirements for qualified personnel, and instructions for proper grounding and protective separation. The manual also contains tables of terminals, technical data, and reference drawings for service and spare parts.
Siemens 611 specifications
| Enable voltage | +24 V |
|---|---|
| Maximum current (total group) | 500 mA |
| Voltage tolerance (including ripple) | 21 V to 30 V |
| Typical current consumption | 50 mA at 24 V |
| Maximum ambient temperature | 40 °C |
| Installation altitude limit | < 1000 m |
Source: Siemens SIMODRIVE 611 Drive Converters Configuration Manual
All Siemens 611 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What line supply voltages can the SIMODRIVE 611 be connected to?
It can be directly connected to TN line supplies with rated voltages 3‑phase 380 V AC (with derating), 3‑phase 400 V AC, 3‑phase 415 V AC and 3‑phase 480 V AC.
From: Siemens SIMODRIVE 611 Drive Converters Configuration Manual
Who is allowed to repair SIMODRIVE 611 converters?
Repairs may be performed only by workshops authorized by Siemens that use genuine spare parts.
From: Siemens SIMODRIVE 611 Drive Converters Configuration Manual
What is the required minimum cross‑section for the protective conductor?
A copper protective conductor with a minimum cross‑section of 10 mm² must be connected.
What is the maximum permissible test voltage for a high‑voltage test?
The maximum permissible test voltage is 1.8 kV DC Phase‑PE.
