Key facts
- Brand
- Siemens
- Model
- MP 270B
- Category
- Industrial Supply
- Industry
- Industrial
- Documents
- 6
- Languages
- EN · ZH
- Last added
- 2000-01-01
Start here
Siemens SIMATIC HMI TP 270 / OP 270 / MP 270B Operating Guide
The guide is intended for users, commissioning engineers, service technicians and maintenance staff who work with the SIMATIC HMI devices. It covers required safety precautions, hardware layout, installation, connection, and the use of WinCC flexible software for configuration and runtime.
Key sections include safety and general information, layout configuration, installation, operation elements, system configuration, project preparation, runtime functions, maintenance, technical data and a glossary. Contact information for Siemens technical support worldwide is also provided. This manual is written in Chinese.
Siemens MP 270B specifications
| Display resolution | 640 × 480 pixels |
|---|---|
| CPU | RISC CPU |
| Flash storage | 5 Mbyte |
| Dimensions (MP 270B) | 212 mm × 156 mm |
Source: Siemens SIMATIC HMI Multi Panels MP 270B, MP 370, OP 77B, TP 170micro User Manual
All Siemens MP 270B documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Who is allowed to install and operate the HMI equipment?
Only qualified professionals may install, commission, and operate the equipment.
From: Siemens SIMATIC HMI TP 270 / OP 270 / MP 270B Operating Guide
What does the warning triangle symbol indicate?
A warning triangle signals a risk of death or serious personal injury.
From: Siemens SIMATIC HMI TP 270 / OP 270 / MP 270B Operating Guide
What is the order number for the MP 270 device manual?
The order number is 6AV6591-10B01-1AB0.
From: Siemens SIMATIC HMI MP 270B / TP 270 / OP 270 Device Manual
