Siemens G120X Manuals

ManualLib has 6 documents for the Siemens G120X: 1 installation guide, 1 application note, 1 user manual, 3 product leaflets. Every file can be read online or downloaded as a PDF for free.

Installation Guide 1Application Note 1User Manual 1Product Leaflet 3

Key facts

Brand
Siemens
Model
G120X
Industry
Industrial
Documents
6
Languages
ZH · EN
Last added
2026-11-13

Start here

Siemens SINAMICS G120X VFD Operation Instructions

Siemens SINAMICS G120X VFD Operation Instructions

User Manual 1270 pages · 30.3 MB · ZH

This document is the Operation Manual (操作说明) for the Siemens SINAMICS G120X family of variable frequency drives. It serves as a comprehensive guide for qualified personnel to install, wire, debug, and operate the drive in industrial automation applications.

The manual covers the entire lifecycle of the device, starting with basic safety instructions and legal information. It details the physical installation process, including mounting options like wall-through technology and optional components such as power filters and I/O expansion modules. A significant portion is dedicated to wiring procedures for power supplies, motors, and various control interfaces including PROFINET, EtherNet/IP, Modbus RTU, USS, and PROFIBUS. This manual is written in Chinese.

Read online

Siemens G120X specifications

Minimum firmware versionV 1.01
IOP-2 firmwareV2.3 upwards
Compressors supportedup to 4
Technological unit[bar]
Commissioning macro47

Source: Siemens SINAMICS G120X Frequency Converter Pressure Controlled Compressor Application Example

All Siemens G120X documents by type

Installation Guide 1

Mounting, wiring and first power-up. Read it before the hardware goes in.

Application Note 1

How to use the product for one specific task, with worked examples.

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What input voltage range is listed for the inverter?

The document lists an input of 3AC 380 V to 450 V.

From: Siemens SINAMICS G120X Inverter Installation Guide

What enclosure type is shown?

The listed enclosure type is UL Type 1.

From: Siemens SINAMICS G120X Inverter Installation Guide

What is the minimum firmware version for the SINAMICS G120X?

The application parameterization requires minimum firmware version V 1.01.

From: Siemens SINAMICS G120X Frequency Converter Pressure Controlled Compressor Application Example

How many compressors does the pressure control application support?

It supports pressure controlled compressor applications with up to 4 compressors.

From: Siemens SINAMICS G120X Frequency Converter Pressure Controlled Compressor Application Example

What is the firmware version of this manual?

The document specifies Firmware Version V1.01.

From: Siemens SINAMICS G120X VFD Operation Instructions

Who is the manufacturer of this drive?

The manufacturer is Siemens AG Digital Industries.

From: Siemens SINAMICS G120X VFD Operation Instructions
