Key facts
- Brand
- Siemens
- Model
- Box PC 627
- Industry
- Industrial
- Documents
- 2
- Languages
- ZH
- Last added
- 2011-11-25
Start here
Siemens SIMATIC Box PC 627 User Guide
User Manual 44 pages · 1.4 MB · ZH
This guide covers everything needed to set up and operate the SIMATIC Box PC 627, an industrial PC from Siemens. It includes safety instructions, hardware description, installation steps, wiring diagrams, and troubleshooting tips.
The manual also provides detailed specifications such as power options, interface ports, and physical dimensions, along with references to online support resources and service information. This manual is written in Chinese.
Siemens Box PC 627 specifications
| AC Power Input | 120 V / 230 V |
|---|---|
| DC Power Input | 24 V |
| Power Connector | IEC connector |
| Display Interface | DVI/VGA (VGA via DVI/VGA adapter) |
| USB Ports | 4 × USB 2.0 (2 can be high‑current) |
| Ethernet Ports | 2 × RJ45 10/100 Mbps |
All Siemens Box PC 627 documents by type
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Other documents 1
Questions answered in these manuals
How many USB ports are available and what is special about them?
The device has four USB 2.0 ports, but only two can be used as high‑current outputs.
Which video interfaces are provided on the Box PC 627?
A DVI/VGA connector is provided for CRT or LCD monitors, with VGA support via a DVI/VGA adapter.
