Key facts
- Brand
- Siemens
- Model
- 6SE7085-0QX60
- Industry
- Industrial
- Documents
- 2
- Languages
- ZH
- Last added
- 2011-11-03
Start here
Siemens 6SE7085-0QX60 SIMOVERT MASTERDRIVES Vector Control Usage Guide
The document provides a detailed system description of the SIMOVERT MASTERDRIVES vector‑control drive, including hardware layout, dimensions and environmental ratings. It also presents configuration and wiring examples for various installation types such as water‑cooled and single‑unit setups.
Further sections cover EMC design guidelines, function blocks, parameter settings, step‑by‑step parameter configuration, and communication interfaces (USS, PROFIBUS, CAN). The guide is intended for the V3.3 software version and includes diagnostic and troubleshooting information. This manual is written in Chinese.
Siemens 6SE7085-0QX60 specifications
| Software version | V3.3 |
|---|---|
| Supported voltage range (3‑phase) | 380 V‑480 V AC |
| Supported voltage range (3‑phase) | 500 V‑600 V AC |
| Supported voltage range (3‑phase) | 660 V‑690 V AC |
| Order number | 6SE7085-0QX60 |
Source: Siemens 6SE7085-0QX60 Vector Control Usage Guide (Volume 2)
All Siemens 6SE7085-0QX60 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Which software version does this guide apply to?
The guide is intended for devices running software version V3.3.
From: Siemens 6SE7085-0QX60 Vector Control Usage Guide (Volume 2)
What does control word bit 0 represent?
Control word bit 0 is the start/stop command (ON/OFF) for the inverter.
From: Siemens 6SE7085-0QX60 Vector Control Usage Guide (Volume 2)
Which software version does this guide apply to?
It applies only to devices running software version V3.3.
From: Siemens 6SE7085-0QX60 SIMOVERT MASTERDRIVES Vector Control Usage Guide
What is the maximum allowed working pressure for water‑cooled MASTERDRIVES?
The working pressure must not exceed 1 bar.
From: Siemens 6SE7085-0QX60 SIMOVERT MASTERDRIVES Vector Control Usage Guide
