Start here
Siemens LOGO! 0BA6 Device Manual
This manual covers the LOGO! 0BA6 series of programmable logic modules, describing safety warnings, installation methods, wiring diagrams, and programming procedures. It also explains the features of the LOGO! 0BA6 hardware, such as the LCD display, cursor keys, memory, and supported communication interfaces.
Additional sections detail the use of LOGO! software on PC, compatibility with older LOGO! modules, available function blocks, and optional accessories like modems and battery cards. Appendices provide reference tables for function block codes and technical data. This manual is written in Chinese.
Siemens LOGO! 0BA6 specifications
| Storage capacity | 32 KB |
|---|---|
| Number of program blocks | 200 |
| Analog output range | 0‑20 mA (AM2 AQ module) |
Source: Siemens LOGO! 0BA6 User Manual
All Siemens LOGO! 0BA6 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Which LOGO! series does this manual apply to?
The manual is applicable to the LOGO! 0BA6 series of devices.
How much memory does the LOGO! 0BA6 storage card provide?
The storage card provides 32 KB of memory, four times the capacity of earlier models.
What does the LOGO! TD module provide?
The LOGO! TD adds an extra display with four function keys and four cursor keys, allowing text messages and menu navigation.
How many program blocks are available for creating circuits?
The LOGO! 0BA6 series provides 200 program blocks for building control programs.
