Key facts
- Brand
- Siemens
- Model
- A31
- Category
- Cell Phones
- Documents
- 10
- Languages
- EN · ZH
- Last added
- 2012-07-04
Start here
SIEMENS SX1 K1 en A31008-H6300-A1-1-7619 phones Manual
This manual covers safety precautions, basic phone overview, and preparation steps before first use, such as inserting the SIM card and battery. It also explains how to make and receive calls, use the menu, and access additional functions like voice dialing and multimedia.
Later sections describe charging procedures, battery specifications, accessory options, and troubleshooting tips. The document ends with a quality statement and regulatory information. This manual is written in Chinese.
Siemens A31 specifications
| Device current (Ip) | 60 mA |
|---|---|
| Total power dissipation (Prot) | 250 mW |
| Ag input power (Paein) | 10 dBm |
| Junction temperature (Tj) | 150 °C |
| Ambient temperature range | -65 ...+150 |
| Insertion power gain at 1 GHz | 9 dB |
| 3 dB-bandwidth | DC to 2.4 GHz |
Source: Siemens BGA 310 Silicon Bipolar MMIC-Amplifier Preliminary Data Sheet
All Siemens A31 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What is the typical gain of the BGA 310 amplifier at 1.0 GHz?
The amplifier provides a typical gain of 9 dB at 1.0 GHz.
From: Siemens BGA 310 Silicon Bipolar MMIC-Amplifier Preliminary Data Sheet
What is the maximum total power dissipation for the device?
The maximum total power dissipation is 250 mW when the temperature is below 99 °C.
From: Siemens BGA 310 Silicon Bipolar MMIC-Amplifier Preliminary Data Sheet
What is the typical gain of the BGA 312 at 1.0 GHz?
The typical gain is 11 dB.
From: Siemens BGA 312 Silicon Bipolar MMIC Amplifier Preliminary Data Sheet
What is the maximum device current rating?
The maximum device current (Ip) is 60 mA.
From: Siemens BGA 312 Silicon Bipolar MMIC Amplifier Preliminary Data Sheet
What is the typical gain of the BGA 318 amplifier at 1.0 GHz?
The typical gain is 16 dB at 1.0 GHz.
From: Siemens BGA 318 Silicon Bipolar MMIC Amplifier Preliminary Data Sheet
What is the maximum device current for the BGA 318?
The maximum device current is 60 mA.
From: Siemens BGA 318 Silicon Bipolar MMIC Amplifier Preliminary Data Sheet
