Start here
Siemens SGT-400 Industrial Gas Turbine Product Data Sheet
The SGT-400 is a twin‑shaft industrial gas turbine designed for power generation, cogeneration and oil‑&‑gas applications. It provides a nominal 12.90 MW(e) output, high simple‑cycle efficiency (≈35 %) and low emissions, making it suitable for both on‑shore and offshore installations.
Key features include a dual‑fuel Dry Low Emissions (DLE) combustion system, modular package design for easy maintenance, and a Siemens SIMATIC PLC‑based control system. The turbine offers a compact footprint (width 2.85 m, length 14.50 m) and a range of service and support options through Siemens’ global network of authorized service centers.
Siemens T400 specifications
| Power generation | 12.90 MW(e) |
|---|---|
| Frequency | 50 or 60 Hz |
| Electrical efficiency | 34.8 % |
| Heat rate | 10,355 kJ/kWh |
| Compressor pressure ratio | 16.8:1 |
| Exhaust temperature | 555 °C (1,031 °F) |
| Typical emissions | NOx <15 ppmV, CO <10 ppmV |
| Generator voltage | 6 to 13.8 kV |
Source: Siemens SGT-400 Industrial Gas Turbine Product Data Sheet
All Siemens T400 documents by type
Instruction set, parameters and examples for configuring or programming the device.
Questions answered in these manuals
What is the rated power output of the SGT-400?
The SGT-400 is rated for a nominal power output of 12.90 MW(e).
From: Siemens SGT-400 Industrial Gas Turbine Product Data Sheet
What efficiency and emissions levels does the SGT-400 achieve?
It has a simple‑cycle efficiency of about 35 % and an electrical efficiency of 34.8 %, with emissions below 15 ppmV NOx and 10 ppmV CO.
From: Siemens SGT-400 Industrial Gas Turbine Product Data Sheet
What safety symbols are used in the manual?
The manual uses warning triangle symbols that indicate very dangerous, potentially dangerous, and caution situations.
From: Siemens T400 FM458-1 DP SIMADYN D SIMATIC TDC Function Block Explanation Manual
Who is the intended audience for this manual?
It is primarily aimed at programmers and debugging engineers.
From: Siemens T400 FM458-1 DP SIMADYN D SIMATIC TDC Function Block Explanation Manual
