Siemens MultiRanger 100 Manuals

ManualLib has 5 documents for the Siemens MultiRanger 100 (Industrial Robot): 2 user manuals, 2 quick start guides. Every file can be read online or downloaded as a PDF for free.

User Manual 2Quick Start Guide 2

Key facts

Brand
Siemens
Model
MultiRanger 100
Industry
Industrial
Documents
5
Languages
ZH · EN
Last added
2023-10-20

Start here

Siemens MultiRanger 100/200 Quick Solutions Manual

Siemens MultiRanger 100/200 Quick Solutions Manual

Quick Start Guide 12 pages · 807 KB · ZH

This document introduces the Siemens MultiRanger 100/200 series, describing its functional blocks, sensor principles, and typical applications. It includes technical data, safety notes, and contact information for Siemens support in China.

The guide details electrical characteristics, communication interfaces (RS‑232/RS‑485 Modbus RTU), calibration parameters, and part numbers. It also lists wiring diagrams, installation steps, and troubleshooting tips for field technicians and end users. This manual is written in Chinese.

Read online

Siemens MultiRanger 100 specifications

Low‑voltage supply12~30 VDC, 20 W
Current loop inputs0–20 mA / 4–20 mA
RS‑232 interfaceModbus RTU
RS‑485 interfaceModbus

Source: Siemens MultiRanger 100/200 Quick Solutions Manual

All Siemens MultiRanger 100 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Quick Start Guide 2

The shortest path to a working setup, usually only a few pages.

Questions answered in these manuals

How do I install the MultiRanger 100 or 200?

Install using wall mounting, conduit wiring, flush mounting, or panel mounting. Follow the installation instructions for each method.

From: Siemens MultiRanger 100,200 User Manual

Which current loop signals are supported?

Both 0–20 mA and 4–20 mA loops are supported.

From: Siemens MultiRanger 100/200 Quick Solutions Manual

Who is allowed to install and operate the MultiRanger devices?

Only qualified personnel may install and operate the equipment, following the safety warnings in the manual.

From: Siemens MultiRanger 100/200 User Manual

How do you configure the device to ignore false echoes?

Set the appropriate parameter as described in the manual to make the MultiRanger ignore false echoes.

From: Siemens MultiRanger 100/200 User Manual
