Siemens FS 10·2004 MOBY Identification System Service Manual
The MOBY identification system from Siemens provides non‑contact RFID solutions for logistics, industrial production, and transportation. It supports 13.56 MHz (ISO/IEC 15693) and 125 kHz tags, offering high reliability, temperature resistance, and re‑usability.
The manual includes configuration, assembly, and maintenance instructions for the various MOBY variants (D, F, I, E, U, R) and their components such as mobile data storage (MDS) and read/write devices (SLG). It also lists technical data, certification, and integration options with SIMATIC, PROFIBUS, and PC systems. This manual is written in Chinese.
Siemens FS 10·2004 specifications
| Maximum read/write distance (SLG D10 with ANT D5) | 500 mm |
|---|---|
| Protection rating (MDS D139) | IP65 |
| Maximum read/write distance (MDS D100) | 680 mm |
| Maximum read/write distance (MDS D124) | 180 mm |
Source: Siemens FS 10·2004 MOBY Identification System Service Manual
All Siemens FS 10·2004 documents by type
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What is the maximum read/write distance for the SLG D10 with antenna D5?
The SLG D10 with antenna D5 can read and write up to 500 mm.
From: Siemens FS 10·2004 MOBY Identification System Service Manual
Which certification does the MOBY system meet for European markets?
It complies with EN 300 330 certification.
From: Siemens FS 10·2004 MOBY Identification System Service Manual
How many parts can be taught for inspection with the VS110 sensor?
Up to 0‑999 parts can be taught for inspection.
From: Siemens SIMATIC Machine Vision FS 10·2004 Product Catalog
What is the IP rating of the VS110 sensor head?
The sensor head has an IP65 protection rating.
From: Siemens SIMATIC Machine Vision FS 10·2004 Product Catalog
