Key facts
- Brand
- Agilent
- Model
- G1888
- Industry
- Industrial
- Documents
- 10
- Languages
- JA · EN
- Last added
- 2012-07-06
Start here
Agilent G1888 Network Headspace Sampler User Information
The Agilent G1888 Network Headspace Sampler is an automated instrument designed for headspace analysis. This user information guide covers the introduction to headspace theory, detailed descriptions of the instrument's keypad and components, and instructions on preparing samples.
The document further explains how to enter and develop analytical methods, run samples, perform advanced functions such as method chaining and leak testing, and maintain the instrument by replacing parts like sample loops and needles. It also includes a troubleshooting section for common errors.
Agilent G1888 specifications
| Headspace Sampler | G1888 |
|---|---|
| GC Model | 7890A |
| MS Model | 5975 |
| Column | DB-1301 20mx0.18mmx2m |
| Injection Port Temperature | 250 C |
| Oven Final Temperature | 200 C |
| Transfer Line Temperature | 120 C |
Source: Agilent Pharmaceutical Residual Solvents Analysis Application Note
All Agilent G1888 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
How to use the product for one specific task, with worked examples.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What solvents are covered by this method?
The method can analyze 56 types of solvents in a single run.
From: Agilent Pharmaceutical Residual Solvents Analysis Application Note
Which ICH classes are covered?
The method covers all three classes of residual solvents defined by ICH guidelines.
From: Agilent Pharmaceutical Residual Solvents Analysis Application Note
What software is required for the G1888A?
The G2922AA software is required for co-execution control by Agilent GC ChemStation.
From: Agilent G1888A Network Headspace Sampler Selection Guide
Does the G1888A support multiple extraction modes?
Yes, it supports Multiple headspace extraction (MHE) mode and Multiple headspace extraction concentration (MHC) mode.
From: Agilent G1888A Network Headspace Sampler Selection Guide
What is the sample tray capacity?
The G1888 features a 70-sample tray capacity with 12 heating positions for maximum throughput.
From: Agilent G1888 Network Headspace Sampler Product Brochure
Can the system control vial pressure?
Yes, it allows easy switching between built-in pneumatics and GC-EPC control to fit your specific GC configuration.
From: Agilent G1888 Network Headspace Sampler Product Brochure
