The 4100 ExoScan FTIR is a portable, handheld, battery-operated FTIR analyzer. It weighs a mere 3.2 kg, including the data system and batteries, making it easy to carry. It can achieve performance equal to or better than conventional laboratory FTIR spectrometers. A highly rugged, miniature interferometer with large diameter optics and very fast, short internal optical path makes this possible.
The Agilent 4100 ExoScan FTIR is a portable, handheld, battery-operated analyzer designed to achieve superb, non-destructive analysis of solid and liquid samples. It features a highly rugged, miniature interferometer with large diameter optics and very fast internal optical paths, delivering performance equal to or better than conventional laboratory FTIR spectrometers.
| Weight (including data system and batteries) | 3.2 kg |
|---|---|
| Sampling technology | Interchangeable External Reflectance and Single-Reflection Diamond sampling heads |
| Frequency range | 4000-650 cm |
| Beam splitter material | ZnSe |
| Detector type | Temperature-stabilzed DTGS |
| Battery capacity | 10.8 V 4400 mAh lithium ion rechargeable |
| Operating temperature | 0 to 50 C (32 to 120 F) |
It is used for analyzing compounds, coatings, paints, polymers, liquids, solids, and gels.
Yes, it can be mounted on a docking station to be used in the lab just like a benchtop FTIR.
The powerful onboard rechargeable lithium ion battery allows for continuous analysis for more than 3 hours.
