Start here
TOSHIBA TLCS-900/L1 TMP91C025 Manual
This manual introduces the Toshiba TLCS‑900/L1 series microcontroller TMP91C025, a low‑voltage, low‑power 16‑bit MCU intended for a wide range of electronic applications. It includes safety notes, operating restrictions, and general handling information.
Key sections cover the device’s block diagram, pin layout and functions, electrical characteristics, package dimensions, and detailed specifications such as CPU core, DMA channels, timers, serial interfaces, ADC, RTC, and power‑supply requirements. This manual is written in Japanese.
Toshiba TLCS-900 specifications
| Timer type | 16‑bit timer in event counter mode |
|---|---|
| Capture registers | CAP1, CAP2 |
| Interrupt used | INTS5 |
| Edge detection pin | TI8 |
| Cycle time example | 16 µs |
Source: TOSHIBA SP-900-011 Manual
All Toshiba TLCS-900 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- TOSHIBA TLCS-900/L series TMP93CS20 Manual 22 p
- TOSHIBA TLCS-900/L1 TMP91C025 Manual 260 p
- TOSHIBA TLCS-900/H1 series Manual
- TOSHIBA TLCS-900/L1 TMP91C829 Manual
- TOSHIBA TLCS-900/H1 TMP92CM22FG Manual
- TOSHIBA Original CMOS 16-Bit Microcontroller TLCS-900/L Series TMP93PW40 Manual
- TOSHIBA TLCS-900/L1 Manual
- TOSHIBA TLCS-900 Manual
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What does the sample program measure?
It measures the high‑level width of an external pulse using a 16‑bit timer.
Which MCU series is the program targeted for?
The program is created for the TLCS‑900H series of microcontrollers.
What is the CPU clock speed of the TMP91FY42FG?
The microcontroller runs at up to 27 MHz.
From: TOSHIBA Original CMOS 16-Bit Microcontroller TLCS-900/L1 Series TMP91FY42FG Data Sheet
How much built‑in RAM does the TMP91FY42FG provide?
It includes 16 KB of built‑in RAM.
From: TOSHIBA Original CMOS 16-Bit Microcontroller TLCS-900/L1 Series TMP91FY42FG Data Sheet
What is the operating voltage range of the TMP93CS20?
The device operates from 2.7 V to 5.5 V.
What package type does the TMP93CS20 use?
It is supplied in a 144‑pin LQFP package (P‑LQFP144‑1616‑0.40).
