Start here
Toshiba PDR‑T10 User Manual
This manual provides safety precautions, basic operation instructions, and guidance for connecting the Toshiba PDR‑T10 digital still camera to a PC. It also explains the supplied software, battery handling, and power‑supply requirements.
The document includes an index of functions, warranty information, and contact details for technical support in multiple regions.
Toshiba T10 specifications
| Forward Voltage (typ.) | 20 V |
|---|---|
| Forward Current | 30 mA |
| Luminous Intensity (typ.) | 200 mcd |
| Peak Emission Wavelength | 636 nm |
| Devices per Reel | 500 |
Source: TOSHIBA TLSU1102(T10)/TLOU1102(T10)/TLYU1102(T10)/TLGU1102(T10)/TLPGU1102(T10) Manual
All Toshiba T10 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the recommended reflow soldering temperature?
Reflow soldering may be performed up to a maximum of 240 °C, with a typical profile of 140‑160 °C for 10 seconds.
From: TOSHIBA TLSU1102(T10)/TLOU1102(T10)/TLYU1102(T10)/TLGU1102(T10)/TLPGU1102(T10) Manual
How many LED lamps are packed on each reel?
Each reel contains 500 devices.
From: TOSHIBA TLSU1102(T10)/TLOU1102(T10)/TLYU1102(T10)/TLGU1102(T10)/TLPGU1102(T10) Manual
What is the forward voltage of the TLRE1102 LED?
The TLRE1102 has a typical forward voltage of 1.9 V.
From: Toshiba TL(RE,SE,OE,YE,GE,PGE)1102(T10) LED Lamp Datasheet
How many TL series LEDs are packed on each reel?
Each reel contains 500 devices.
From: Toshiba TL(RE,SE,OE,YE,GE,PGE)1102(T10) LED Lamp Datasheet
What should I do if the camera emits smoke, a strange odor, or excessive heat?
Immediately turn the power off and remove the batteries and AC adapter.
Which operating system needs a special USB driver?
Only Windows 98 requires the supplied USB driver; other OSes use their standard drivers.
