STMicroelectronics STM32F405 Manuals

ManualLib has 3 documents for the STMicroelectronics STM32F405 (microcontrollers): 1 programming manual, 1 datasheet, 1 application note. Every file can be read online or downloaded as a PDF for free.

Programming Manual 1Datasheet 1Application Note 1

Key facts

Model
STM32F405
Documents
3
Languages
EN
Last added
2023-10-13

Start here

RM0090 Reference manual STM32F405/415, STM32F407/417, STM32F427/437 and STM32F429/439 advanced Arm®-based 32-bit MCUs

RM0090 Reference manual STM32F405/415, STM32F407/417, STM32F427/437 and STM32F429/439 advanced Arm®-based 32-bit MCUs

Programming Manual 875 pages · 9 MB · EN

This reference manual targets application developers using the STM32F405xx/07xx, STM32F415xx/17xx, STM32F42xxx, and STM32F43xxx microcontrollers. It provides complete information on how to use these devices' memory and peripherals.

The document covers system architecture, including memory organization, boot configuration, and the Embedded Flash memory interface. It details features such as the Adaptive real-time memory accelerator (ART Accelerator) and various erase/program operations.

Read online

STMicroelectronics STM32F405 specifications

CPU CoreARM 32-bit Cortex-M4 CPU with FPU
Maximum Frequency168 MHz
Flash MemoryUp to 1 Mbyte
SRAMUp to 192+4 Kbytes
ADC ChannelsUp to 24 channels
TimersUp to 17 timers
I/O PortsUp to 140 I/O ports
Communication InterfacesUp to 15 communication interfaces
Operating Voltage1.8 V to 3.6 V

Source: STMicroelectronics STM32F405xx/STM32F407xx ARM Cortex-M4 MCU Datasheet

All STMicroelectronics STM32F405 documents by type

Programming Manual 1

Instruction set, parameters and examples for configuring or programming the device.

Datasheet 1

Ratings, dimensions and ordering codes, for selection and design work.

Application Note 1

How to use the product for one specific task, with worked examples.

Questions answered in these manuals

What is the purpose of this document?

It provides complete information on how to use the STM32F4 microcontroller memory and peripherals.

From: RM0090 Reference manual STM32F405/415, STM32F407/417, STM32F427/437 and STM32F429/439 advanced Arm®-based 32-bit MCUs

What type of microcontrollers does this manual cover?

This manual covers STM32F405xx/07xx, STM32F415xx/17xx, STM32F42xxx, and STM32F43xxx microcontrollers.

From: RM0090 Reference manual STM32F405/415, STM32F407/417, STM32F427/437 and STM32F429/439 advanced Arm®-based 32-bit MCUs

What is the maximum operating frequency of the STM32F405xx/STM32F407xx?

The maximum operating frequency is 168 MHz.

From: STMicroelectronics STM32F405xx/STM32F407xx ARM Cortex-M4 MCU Datasheet

Does the STM32F405xx/STM32F407xx include a Floating Point Unit?

Yes, it includes an ARM Cortex-M4 CPU with FPU.

From: STMicroelectronics STM32F405xx/STM32F407xx ARM Cortex-M4 MCU Datasheet

What microcontrollers are covered in this application note?

The document covers STM32F405/07xx and STM32F415/417xx high-performance MCUs with DSP and FPU instructions.

From: STMicroelectronics AN4044 Application Note Using FPU with STM32F4 MCUs

Which development tool is mentioned as applicable?

The STM3240G-EVAL evaluation board is listed as an applicable development tool.

From: STMicroelectronics AN4044 Application Note Using FPU with STM32F4 MCUs
