Siemens SKD32/SKD82/SKD62/SKD60 Electric Hydraulic Valve Actuator Manual
This manual provides detailed information for the SKD32, SKD82, SKD62 and SKD60 electric hydraulic valve actuators, including model overviews, electrical specifications, installation steps, and adjustment procedures. It also covers optional accessories, safety notes, and troubleshooting tips for HVAC applications.
The document explains the spring‑reset function, LED status indicators, additional frost‑protection signals, and how to configure action direction, travel limits and sequence control using the built‑in dip switches. This manual is written in Chinese.
Siemens SKD62 specifications
| SKD32 operating voltage | AC 230 V |
|---|---|
| SKD82 operating voltage | AC 24 V |
| SKD62 operating voltage options | AC 24 V, DC 0‑10 V, 4‑20 mA or 0‑1000 µA |
| Maximum drive torque | 1000 N |
| Travel range | 20 mm |
Source: Siemens SKD32/SKD82/SKD62/SKD60 Electric Hydraulic Valve Actuator Manual
All Siemens SKD62 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the operating voltage for the SKD32 actuator?
The SKD32 actuator operates on AC 230 V.
From: Siemens SKD32/SKD82/SKD62/SKD60 Electric Hydraulic Valve Actuator Manual
Which additional signals are available for the SKD62UA model?
The SKD62UA can use the QAF21 and QAF61 signals for frost‑protection monitoring.
From: Siemens SKD32/SKD82/SKD62/SKD60 Electric Hydraulic Valve Actuator Manual
