Omron F3SX Safety Controller User Manual
User Manual 24 pages · 2.3 MB · ZH
The F3SX is a safety controller that integrates input, output and diagnostic functions in a compact, modular design. It supports DeviceNet safety systems and complies with international safety standards such as IEC61508, EN954‑1, EN50178, UL508 and others.
The manual details module types, connection methods, LED status indicators, RS‑232 communication, and how to set delay times using the F3SX‑CD100 software or terminal switches. It also provides dimension and weight data for each module variant. This manual is written in Chinese.
Omron F3SX specifications
| Module size (F3SX‑NR) | 45.0 mm, approx. 0.3 kg |
|---|---|
| Module size (F3SX‑N‑D1R) | 90.0 mm, approx. 0.5 kg |
| Compliance | IEC61508, EN954‑1, EN50178, UL508, UL1998 |
All Omron F3SX documents by type
User Manual 2
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What safety devices can be connected to the F3SX?
It can be connected to safety light curtains, safety door switches, emergency‑stop buttons and other safety sensors.
