ATEN Altusen PN0108 Manuals

ManualLib has 5 documents for the ATEN Altusen PN0108: 2 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 2

Key facts

Brand
ATEN
Model
PN0108
Documents
5
Languages
EN · KO · ZH
Last added
2023-10-17

Start here

ATEN PN0108 Power over the NET User Manual

ATEN PN0108 Power over the NET User Manual

User Manual 91 pages · 2.4 MB · KO

This document is the user manual for the ATEN PN0108 Power over the NET device. It covers hardware setup, including stacking and rack mounting, as well as browser and out-of-band operation procedures. The guide details how to log in, manage devices, configure the network environment, and handle safe shutdowns and reboots. This manual is written in Korean.

Read online

ATEN Altusen PN0108 specifications

Power CharacteristicsPN0108A: 100-240 VAC; 15A; PN0108G: 400-240 VAC; 10A
Power Inlets1 x IEC 60320/C14 (M)
Power Outlets8 x IEC 60320/C13 (F)
Operating Temperature0-40°C
HousingMetal
Weight3.7 kg
Dimensions43.20 x 21.00 x 4.40 cm

Source: ATEN PN0108 Power over the NET Installation and Operation Guide

All ATEN Altusen PN0108 documents by type

Questions answered in these manuals

What is the maximum number of devices the PN0108 can manage?

Up to 128 devices can be managed in a complete installation, including up to 15 additional PN0108 units in a daisy chain.

From: ATEN PN0108 Power over the NET Installation and Operation Guide

How many devices can be managed in a daisy chained installation?

Up to 128 devices can be managed on a complete daisy chained installation.

From: ATEN PN0108 Power over the NET Installation and Operation Guide

What is the maximum power consumption of the PN0108 at 230V?

The maximum power consumption is 2300W when operating at 230V and 50Hz.

From: ATEN PN0108 Power over the NET User Manual

What is the physical size of the PN0108 unit?

The unit dimensions are 43.2 x 21 x 4.4 cm for length, width, and height.

From: ATEN PN0108 Power over the NET User Manual

What are the input voltage ranges for the PN0108?

The unit accepts 100‑120 V at 12 A or 220‑240 V at 10 A, both at 50/60 Hz.

From: Aten PN0108 Power Supply Management User Manual

What type of power cable should be used for the PN0108?

Use the supplied cable or a replacement with the same standard: 0.75 mm² × 3G (H05V‑V‑F or VW‑1) rated for 10 A, compatible with VDE 0620/0625 or EN 60320 specifications.

From: Aten PN0108 Power Supply Management User Manual
