ATEN VM0404 Manuals

ManualLib has 3 documents for the ATEN VM0404 (Other Electronics): 3 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 3

Key facts

Brand
ATEN
Model
VM0404
Industry
Computers
Documents
3
Languages
EN · ZH
Last added
2026-10-19

Start here

ATEN VM0404 4x4 Matrix Video Switcher User Manual

ATEN VM0404 4x4 Matrix Video Switcher User Manual

User Manual 32 pages · 364 KB · ZH

This user manual covers the installation, operation, and configuration of the ATEN VM0404, a 4x4 matrix video switcher with audio functionality. It includes details on hardware setup, front panel and infrared remote control usage, and switching video sources to specific outputs. This manual is written in Chinese.

Read online

ATEN VM0404 specifications

Resolution Supportup to 1920 x 1440
Bandwidthup to 300 MHz
Transmission Distanceup to 30m
Power Voltage230V phase-to-phase

Source: ATEN VM0404 4x4 Video Matrix Switch with Audio User Manual

All ATEN VM0404 documents by type

User Manual 3

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the maximum transmission distance for the VM0404?

The device supports long distance transmission of up to 30 meters.

From: ATEN VM0404 4x4 Video Matrix Switch with Audio User Manual

Can the VM0404 be controlled via RS-232?

Yes, the switch features a built-in bi-directional RS-232 serial port for control via a controller, PC, or software.

From: ATEN VM0404 4x4 Video Matrix Switch with Audio User Manual

What is the maximum power consumption of the VM0404H?

The unit consumes up to 9 W at 5.3 V DC.

From: ATEN VM0404H Matrix HDMI Switch User Manual

What is the maximum video resolution supported?

The device supports resolutions up to 1920 x 1440 @ 60Hz.

From: ATEN VM0404 4x4 Matrix Video Switcher User Manual

What is included in the package?

The package includes the VM0404 unit, a power adapter, and this user manual.

From: ATEN VM0404 4x4 Matrix Video Switcher User Manual
