ATEN CV-130A Manuals

ManualLib has 3 documents for the ATEN CV-130A (Other): 3 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 3

Key facts

Brand
ATEN
Model
CV-130A
Category
Other
Documents
3
Languages
EN · ZH
Last added
2023-10-27

Start here

ATEN CV-130A / CV-130B Sun Console Converter User Manual

ATEN CV-130A / CV-130B Sun Console Converter User Manual

User Manual 20 pages · 867 KB · EN

The ATEN CV-130A / CV-130B Sun Console Converter is designed to convert Sun console signals for use with standard peripherals. This user manual covers all aspects of installation, configuration, and operation to help you get the most from the unit.

The manual includes EMC information, package contents, safety instructions, technical support contacts, product specifications, troubleshooting steps, and details on the ATEN limited hardware warranty.

Read online

ATEN CV-130A specifications

Connector to SPHD‑15 switch (CV‑130A)1 × SPHD‑15
Connector to PS/2‑VGA switch (CV‑130B)2 × 6‑pin mini DIN
Connector to Sun video port1 × 13W‑3
Connector to Sun keyboard/mouse1 × Mini‑DIN‑8
Supported video resolutions1152 × 900, 1280 × 1024, 1600 × 1200
Operating temperature0 °C to 50 °C
Storage temperature-20 °C to 60 °C
Humidity (non‑condensing)0 % to 80 % RH
Cable length1.8 m
Housing dimensions10.65 × 4.2 × 2.31 cm
Weight (CV‑130A)0.2 kg

Source: ATEN CV-130A / CV-130B Signal Converter Cable User Manual

All ATEN CV-130A documents by type

User Manual 3

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

How can I register my ATEN product online?

You can register your product at the ATEN online support center at http://eservice.aten.com.

From: ATEN CV-130A / CV-130B Sun Console Converter User Manual

What is the duration of the ATEN limited hardware warranty?

ATEN warrants its hardware against flaws in materials and workmanship for a period of two years from the date of original purchase.

From: ATEN CV-130A / CV-130B Sun Console Converter User Manual

What video resolutions are supported by the converter?

The converter supports Sun‑specific resolutions of 1152 × 900, 1280 × 1024, and 1600 × 1200.

From: ATEN CV-130A / CV-130B Signal Converter Cable User Manual

Do I need an external power adapter for the CV‑130A/B?

No external power adapter is required.

From: ATEN CV-130A / CV-130B Signal Converter Cable User Manual

How do I install the CV‑130A/130B converter?

Connect the converter cable to the appropriate ports on the KVM switch and the Sun workstation, ensuring all devices are powered off and grounded before connection.

From: Hongzheng CV-130A/130B User Manual

Which display resolutions are supported by the converter?

The device supports Sun‑specific resolutions of 1152×900, 1280×1024, and 1600×1200.

From: Hongzheng CV-130A/130B User Manual
