Start here
Analog Devices AD9516-2 Product Handbook
The AD9516-2 is a 14‑output clock generator with an integrated 2.2 GHz VCO. It offers low phase‑noise PLL operation, programmable delays, and automatic reference switchover. The device supports LVPECL, LVDS, and CMOS output standards and can be powered from a single 3.3 V supply.
The handbook provides detailed specifications, functional block diagrams, timing characteristics, and application guidance for high‑speed data‑converter clocking, networking line cards, and wireless transceivers. It also includes power‑supply requirements, pin descriptions, and recommended PCB layout practices for CMOS outputs.
Analog Devices AD9516-2 specifications
| LVPECL output frequency | 1.6 GHz (6 pairs) |
|---|---|
| LVDS output frequency | 800 MHz (4 pairs) |
| CMOS output frequency | 250 MHz |
| Supply voltage (Vs) | 3.3 V (typical) |
| Operating temperature range | -40 °C to +85 °C |
All Analog Devices AD9516-2 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum LVPECL output frequency of the AD9516-2?
The device provides six LVPECL output pairs that can operate up to 1.6 GHz.
What supply voltage does the AD9516-2 require?
It operates from a 3.3 V supply (typical 3.3 V, range 3.135 V to 3.465 V).
What is the frequency range of the on‑chip VCO?
The on‑chip VCO tunes from 2.05 GHz to 2.33 GHz.
How many LVPECL outputs does the AD9516‑2 provide?
It provides six LVPECL outputs arranged in three pairs.
