Analog Devices AD9518-1 6-Output Clock Generator Data Sheet
The AD9518-1 provides six LVPECL clock outputs (in three pairs) with up to 2.95 GHz frequency, an on‑chip VCO that tunes from 2.30 GHz to 2.65 GHz, and programmable dividers and phase delays. It operates from a single 3.3 V supply and supports differential, LVDS, or CMOS reference inputs up to 250 MHz.
Designed for high‑performance clock distribution, the device is suited for 10/40/100 Gb/sec networking, high‑speed ADC/DAC clocking, and wireless transceivers. Key specifications include low additive jitter (225 fs rms), sub‑10 ps channel‑to‑channel skew, and operation over –40 °C to +85 °C.
Analog Devices AD9518-1 specifications
| VCO Frequency Range | 2.30 GHz – 2.65 GHz |
|---|---|
| Operating Temperature Range | −40 °C to +85 °C |
| Maximum LVPECL Output Frequency | 2.95 GHz |
| Output Differential Voltage (typical) | 550 mV |
Source: Analog Devices AD9518-1 6-Output Clock Generator Data Sheet
All Analog Devices AD9518-1 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the VCO frequency range of the AD9518-1?
The on‑chip VCO tunes from 2.30 GHz to 2.65 GHz.
From: Analog Devices AD9518-1 6-Output Clock Generator Data Sheet
How many LVPECL outputs does the AD9518-1 provide?
The device provides six LVPECL outputs arranged in three pairs.
From: Analog Devices AD9518-1 6-Output Clock Generator Data Sheet
What is the tuning range of the on‑chip VCO?
The on‑chip VCO tunes from 2.30 GHz to 2.65 GHz.
How many LVPECL outputs does the AD9518‑1 provide?
The AD9518‑1 provides six LVPECL outputs arranged in three pairs.
