Key facts
- Brand
- Philips
- Model
- CD270
- Documents
- 2
- Languages
- ZH
- Last added
- 2011-10-14
Start here
Philips CD270/CD275 Quick Start Guide
This guide provides step‑by‑step instructions for first‑time users of the Philips CD270/CD275 phone dock. It covers unpacking, connecting the dock to power and telephone sockets, installing the mobile phone, and charging the built‑in battery.
Additional sections describe configuring the phone’s settings, making and receiving calls, using the answer‑machine (CD275 only), and where to find further help online. This manual is written in Chinese.
Philips CD270 specifications
| Screen | Amber LCD backlight |
|---|---|
| Battery | Ni‑MH AAA 1.2 V 550 mAh |
| Weight (handset) | 125.6 g |
| Dimensions (handset) | 46.1 × 164.5 × 27.5 mm |
| Operating temperature | 0 °C to +35 °C |
| Storage temperature | -20 °C to +45 °C |
| Maximum call time | 12 hours |
| Phonebook capacity | 100 records |
| Redial list capacity | 5 records |
| Call log capacity | 20 records |
Source: Philips CD270/CD275 User Manual
All Philips CD270 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
What should I do if the phone shows [UNREGISTERED]?
Register the phone according to the registration procedure described in the manual.
Why won’t the phone charge on the charger?
Make sure the battery is inserted correctly and the phone is placed properly on the charger.
How long should the battery be charged before first use?
Charge the battery for 16 hours before first use.
How do I add a new contact to the phonebook?
Press MENU, select PHONEBOOK > NEW ENTRY, confirm, then enter the name and number and press OK for each.
