Key facts
- Brand
- Panasonic
- Model
- AN90B00S Series
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-07
Start here
AN90BOO/AN90BOOS Series Transistor Arrays
Datasheet 7 pages · 271 KB · EN
This document provides technical specifications for the Panasonic AN90B00/AN90B00S Series Transistor Arrays. It includes a list of available models within the series, such as the AN90B10, AN90B20, and AN90B80 variants.
Read onlinePanasonic AN90B00S Series specifications
| Output Current (Ip) | 25 mA |
|---|---|
| Breakdown voltage (Vceo) | 24 V |
| Package Type | 16-Lead PANAFLAT Package (SO-16D) |
All Panasonic AN90B00S Series documents by type
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum output current rating for these transistor arrays?
The absolute maximum output current is rated at 25 mA.
What is the specified breakdown voltage for this device series?
The breakdown voltage (Vceo) is 24 V.
What is the output current rating of the AN90B00 series?
The output current (Ip) is specified as 25 mA.
What is the breakdown voltage for these transistor arrays?
The breakdown voltage (Vero) is 24 V.
