Panasonic WV-CW484F / WV-CW480S User Manual
This manual provides safety instructions, wiring information, and handling precautions for the Panasonic WV-CW484F and WV-CW480S colour CCTV cameras. It covers required earthing, proper power connections, and environmental limits to ensure reliable operation.
The document also details camera features such as the 1/3‑inch Super‑Dynamic CCD, 2× variable focal lens, high resolution, and automatic night‑mode switching. Installation guidance, mounting options, dehumidifying device usage, and troubleshooting steps are included, along with technical specifications and optional accessories.
Panasonic WV-CW480 specifications
| Image sensor | Super‑Dynamic 1/3 inch CCD |
|---|---|
| Lens | 2× variable focal lens |
| Power source (WV‑CW484F) | 12 V DC / 24 V AC |
| Power source (WV‑CW480S) | 220 V‑240 V AC |
| Operating temperature range | -10 °C to +50 °C |
| Extended temperature range (with optional heater) | -30 °C to +50 °C |
All Panasonic WV-CW480 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What power supply is required for the WV‑CW484F camera?
The WV‑CW484F requires a 12 V DC or 24 V AC power source.
Does the camera automatically switch to night mode in low light?
Yes, the camera can be configured to automatically switch to black‑and‑white mode under low‑light conditions.
What is the minimum illumination required in color mode?
The camera needs a minimum illumination of 0.6 Lux in color mode.
What IP protection level does the WV‑CW480 series have?
It meets the IP66 standard for dust and water protection.
