Key facts
- Brand
- Panasonic
- Model
- PT-LB50
- Documents
- 3
- Languages
- JA
- Last added
- 2012-08-07
Start here
Panasonic PT-LB50/PT-LB55/PT-LB60 LCD Projector User Manual
This manual covers important safety information, including grounding requirements and fire‑prevention measures, before the projector is installed. It also explains how to prepare the unit, connect power and RS‑232C interfaces, and perform basic operation such as power on/off, image adjustment, and volume control.
Further sections describe automatic image correction, projection size calculations, lamp maintenance, and troubleshooting tips. The document is intended for end‑users to safely install, operate, and maintain the PT‑LB series LCD projectors. This manual is written in Japanese.
Panasonic PT-LB50 specifications
| Supported Interface | RS‑232C |
|---|---|
| Series | PT‑LB50 / PT‑LB55 / PT‑LB60 |
| Grounding Requirement | Must be grounded |
Source: Panasonic PT-LB50/PT-LB55/PT-LB60 LCD Projector User Manual
All Panasonic PT-LB50 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What safety precautions must be taken before using the projector?
The equipment must be grounded, fire‑hazard precautions must be observed, and the ground pin must not be removed.
From: Panasonic PT-LB50/PT-LB55/PT-LB60 LCD Projector User Manual
How do I connect the projector to a PC?
Use a cable that includes an RS‑232C interface to connect the projector to the computer.
From: Panasonic PT-LB50/PT-LB55/PT-LB60 LCD Projector User Manual
