Start here
Panasonic WV-ASM200/CH Hard Disk Video Recorder Management Software User Manual
This manual describes the Panasonic WV-ASM200/CH hard‑disk video recorder management software, which runs on Microsoft Windows and allows users to monitor, playback, download and control multiple Panasonic network video recorders, encoders and cameras over a LAN or Internet.
It covers software configuration, system setup, registration limits, compatible devices, features, licensing, and operation procedures, including handling of MPEG‑4/H.264 video streams and multi‑screen monitoring. This manual is written in Chinese.
Panasonic WV-ASM200 specifications
| Maximum registered video recorders | 100 |
|---|---|
| Maximum registered encoders | 64 |
| Maximum registered cameras | 256 |
| Maximum registered users | 32 |
| User levels | 5 |
| Maximum registered groups | 400 |
| Maximum registered sequences | 10 |
| Maximum registered maps | 100 |
| Maximum alarm log entries | 30000 |
| Maximum device error log entries | 1000 |
| Maximum network error log entries | 1000 |
| Maximum system log entries | 1000 |
| Maximum operation log entries | 100000 |
| Maximum searchable results | 1000 |
Source: Panasonic WV-ASM200/CH Hard Disk Video Recorder Management Software User Manual
All Panasonic WV-ASM200 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I register the function‑expansion option?
Enter the registration key and ID shown in the activation key card (e.g., 0402‑0035‑000A‑1234 and 248A‑69C5) into the WV‑ASM200 software.
From: Panasonic WV-ASM200 Fish Eye Network Camera Function Expansion Option User Manual
What image capture mode must be selected for the compensation function to work?
The camera must be set to a fisheye capture mode (e.g., 3M 鱼眼[4:3] or 1.3M 鱼眼[4:3]) and the appropriate resolution (2048×1536 or 1280×960 for M‑JPEG, 1280×960 for H.264).
From: Panasonic WV-ASM200 Fish Eye Network Camera Function Expansion Option User Manual
How many video recorders can be registered in the software?
The software can register up to 100 video recorders.
From: Panasonic WV-ASM200/CH Hard Disk Video Recorder Management Software User Manual
What is required for the software to run?
A registered license key is required; without it the software will not operate.
From: Panasonic WV-ASM200/CH Hard Disk Video Recorder Management Software User Manual
