This document introduces the features and characteristics of the E3Z series photoelectric switches, including models such as E3Z-L, E3Z-B, E3ZM, E3Z-G, E3T, E3S-C, E3G, E3S-CL, and E3Z-LS. The E3ZM model features a stainless steel housing, making it suitable for the food industry with its hygienic, robust, and washable design. The E3Z series products are widely used in various fields such as information technology and the food industry.
This manual describes the Omron E3ZM series built‑in photoelectric switch, highlighting its stainless‑steel SUS316L housing, IP69K protection, and suitability for harsh food‑processing environments. It lists the various sensor variants, detection distances, and optical characteristics.
The guide includes installation fixtures, wiring diagrams, connection options (wire‑lead and connector types), power‑supply requirements, and detailed performance specifications such as temperature range, humidity limits, and output configurations. Accessories such as reflective plates and mounting brackets are also covered. This manual is written in Chinese.
| Power supply voltage | DC10‑30 V |
|---|---|
| Operating temperature range | -25 °C to +55 °C |
| Housing material | Stainless steel SUS316L |
| Light source wavelength | 650 nm (infrared LED) |
The recommended power supply voltage is between DC10 V and DC30 V.
The housing is made of stainless steel SUS316L, offering excellent corrosion resistance.
