Key facts
- Brand
- ABB
- Model
- ACH580
- Industry
- Industrial
- Documents
- 4
- Languages
- ZH · EN
- Last added
- 2026-10-07
Start here
ABB ACH580 HVAC Control Program Firmware Manual
This firmware manual describes the operation, configuration, and parameter settings of the ABB ACH580 HVAC drive. It includes sections on startup, I/O control, identification runs, control panel layout, default HVAC values, program functions, and detailed parameter groups.
The document also covers fault tracking, built‑in bus communication (EFB), bus‑adapter control, and control chain diagrams, with extensive tables of parameter codes, safety information, and service procedures. This manual is written in Chinese.
ABB ACH580 specifications
| THDi (harmonic distortion) with ULH drive | ≈ 3 % |
|---|---|
| System efficiency with ULH drive (typical load) | ≈ 87.9 % |
| Harmonic content under rated load | 3 % |
| Power factor improvement | approaches 1.0 |
Source: ABB ACS880/ACH580/ACQ580 Low Harmonic and Energy Feedback Inverter Application Note
All ABB ACH580 documents by type
Disassembly, diagnostics and part numbers, for repair.
Mounting, wiring and first power-up. Read it before the hardware goes in.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
How do I start the ACH580 drive using the HVAC control panel?
Use the first‑start assistant on the HVAC control panel to start the drive.
What should I check if a brake chopper short‑circuit fault occurs?
Ensure the brake resistor is connected and not damaged.
How should the main switch be used safely?
Stop the drive, wait until the motor has stopped, turn the main switch to the OFF position, and attach a lock before working on the drive.
Does the main switch isolate the input power cables?
No, the main switch does not isolate the input cables; they must be isolated at the distribution board or by opening the supply transformer disconnector before work.
What is the typical THDi for ABB's ULH drives?
ABB’s ULH drives achieve a total harmonic distortion (THDi) of about 3 % under typical operating conditions.
From: ABB ACS880/ACH580/ACQ580 Low Harmonic and Energy Feedback Inverter Application Note
How does an active front end (AFE) drive reduce harmonics?
An AFE drive uses a DC‑bus capacitor and an LCL filter, eliminating the harmonic‑generating rectifier stage and thus keeping the grid current waveform close to a pure sine wave.
From: ABB ACS880/ACH580/ACQ580 Low Harmonic and Energy Feedback Inverter Application Note
