Start here
ABB ACS580-01 Variable Frequency Drive Quick Installation and Startup Guide
This document serves as a quick reference for installing and starting up the ABB ACS580-01 Variable Frequency Drive (VFD). It covers essential safety precautions, physical installation steps such as wall mounting and cable connection, and specific checks required before operation. The guide includes instructions on verifying capacitor health, selecting appropriate power cables and fuses based on drive ratings, and ensuring proper cooling conditions. This manual is written in Chinese.
Read onlineABB ACS580-01 specifications
| Power Range | 0.75 to 250 kW, 1.0 to 350 hp |
|---|---|
| Effective Date | 2017-05-31 |
| Standard Control Program Firmware Manual Part Number | 3AXD50000016097 |
Source: ABB ACS580-01 Variable Frequency Drive Hardware Manual
All ABB ACS580-01 documents by type
The shortest path to a working setup, usually only a few pages.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What is the power range of the ACS580-01 drive?
The drive is rated for a power range of 0.75 to 250 kW, or 1.0 to 350 hp.
From: ABB ACS580-01 Variable Frequency Drive Hardware Manual
Where can I find the English version of this manual?
The English version is based on document number 3AXD50000044794.
From: ABB ACS580-01 Variable Frequency Drive Hardware Manual
How should the main switch be used safely?
Stop the drive, wait until the motor has stopped, turn the main switch to the OFF position, and attach a lock before working on the drive.
Does the main switch isolate the input power cables?
No, the main switch does not isolate the input cables; they must be isolated at the distribution board or by opening the supply transformer disconnector before work.
