This document is about SIMODRIVE 611 planning guide, introduces system configuration, motor selection and position/speed sensing, power modules, control modules, infeed modules, line supply connection, supplementary system components, important circuit information, cabinet design and EMC, block diagrams, connection diagrams, drawings, EC declaration of conformity, abbreviations and terminology, references, index etc.
The SIMODRIVE 611 Planning Guide is intended for qualified personnel who configure, assemble and commission drive groups with SIMODRIVE components. It covers system configuration, motor selection, power and control modules, infeed modules, line supply connection, and supplementary system components.
The document includes safety symbols, technical data tables, wiring diagrams, and EMC considerations. It is part of Siemens' Manufacturer/Service Documentation and is updated for the 6SN11‑series drive converters.
| Minimum protective conductor cross‑section | 10 mm² |
|---|---|
| Maximum permissible high‑voltage test voltage | 1.8 kV DC Phase‑PE |
A copper protective conductor with a minimum cross‑section of 10 mm² must be connected.
The maximum permissible test voltage is 1.8 kV DC Phase‑PE.
