Key facts
- Brand
- ROHM
- Model
- BU52051NVX
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-04-12
Start here
ROHM BU52001GUL, BU52011HFV, BU52021HFV, BU52015GUL, BU52025G, BU52051NVX, BD7411G Bipolar Detection Hall ICs Datasheet
The BU52001GUL series Hall ICs are bipolar detection magnetic switches that output a low level when a magnetic field from either the S‑pole or N‑pole is detected. They are offered in several package types and supply‑voltage options for use in mobile phones, notebooks, cameras, and other white‑goods.
Key features include micropower operation, dual‑output capability for some models, high ESD resistance (8 kV HBM), and a range of supply voltages from 1.8 V to 5.0 V. Detailed electrical and magnetic characteristics, pin assignments, and mechanical dimensions are provided for each device variant.
All ROHM BU52051NVX documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
How many output pins does the BU52015GUL have?
It provides two output pins: OUT1 (active low) and OUT2 (active high).
How should the IC be protected from strong light exposure?
Provide a shield or other protective measures to block strong light such as halogen or UV lamps.
From: ROHM BU52011GUL BU52011HFV BU52021HFV BU52015GUL BU52025G BU52051NVX BD7411G TECHNICAL NOTE
What is the typical output current of these Hall ICs?
The typical output current is 1 mA.
From: ROHM BU52011GUL BU52011HFV BU52021HFV BU52015GUL BU52025G BU52051NVX BD7411G TECHNICAL NOTE
