Motorola MC68306 FC16 Integrated EC000 Processor User's Manual
The document serves as a comprehensive user guide for the Motorola MC68306 EC000 Integrated Processor. It details the complete documentation package which includes this manual, the Programmer's Reference Manual, and a Product Brief. The text emphasizes that all operating parameters must be validated by customer technical experts before use.
Read onlineMotorola MC68306 specifications
| Supply Voltage | 4.75 to 5.25 V |
|---|---|
| Operating Temperature Range | 0 to 70 °C |
| Power Dissipation | 0.525 W |
| Input Low Voltage (except clocks) | 0.8 V |
| Clock Input High Voltage | 0.8*(VCC) to V CC |
| Clock Input Low Voltage | 0 to 0.2 *V CC |
Source: MC68306UMAD/AD Addendum to MC68306 Integrated EC000 Processor User's Manual
All Motorola MC68306 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What are the pullup recommendations for the MC68306?
The pullup resistor recommendations are intended as general guidelines only, and specific values can be modified to suit individual applications.
From: MC68306UMAD/AD Addendum to MC68306 Integrated EC000 Processor User's Manual
What is the minimum reset time for the MC68306?
The reset time should be a minimum of 132 clocks.
From: MC68306UMAD/AD Addendum to MC68306 Integrated EC000 Processor User's Manual
What documents are included in the complete documentation package for the MC68306?
The package consists of the User's Manual, the M68000PM/AD Programmer's Reference Manual, and the Product Brief.
From: Motorola MC68306 FC16 Integrated EC000 Processor User's Manual
Who is responsible for validating operating parameters?
All operating parameters must be validated by customer technical experts.
From: Motorola MC68306 FC16 Integrated EC000 Processor User's Manual
What is the primary advantage of using the MC68306?
It reduces design time by providing valuable system elements pre-packaged in one chip.
From: Motorola MC68306 Integrated EC000 Processor Product Brief
Is the MC68306 compatible with existing code?
Yes, it affords access to a broad base of established real-time kernels and operating systems due to complete code compatibility.
From: Motorola MC68306 Integrated EC000 Processor Product Brief
