Motorola MC74AC113/MC74ACT113 Dual JK Flip-Flop Datasheet
This document provides technical specifications for the Motorola MC74AC113 and MC74ACT113 devices. These are dual high-speed completely independent transition clocked JK flip-flops that can also operate as D flip-flops by connecting J and K inputs together.
The datasheet details maximum ratings, recommended operating conditions, DC and AC characteristics for both 74AC and 74ACT series variants at supply voltages of 3.0V to 5.5V. It includes truth tables, logic diagrams, timing parameters such as propagation delay and setup time, capacitance values, and outline dimensions for N (DIP) and D (SOIC) plastic packages.
Motorola MC74AC11 specifications
| Supply Voltage Range (Vcc) | -0.5 to +7.0 V (Max), 2.0 to 6.0 V (Recommended) |
|---|---|
| Operating Temperature Range | -40 to +85 °C |
| Output Current (Source/Sink) | 24 mA |
| Maximum Clock Frequency | 145 MHz |
| Input Capacitance | 45 pF |
Source: Motorola MC74AC113/MC74ACT113 Dual JK Flip-Flop Datasheet
All Motorola MC74AC11 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Can the JK flip-flop operate as a D flip-flop?
Yes, by connecting the J and K inputs together.
From: Motorola MC74AC113/MC74ACT113 Dual JK Flip-Flop Datasheet
What are the recommended supply voltages?
The recommended operating conditions specify 3.0V, 4.5V, or 5.0V.
From: Motorola MC74AC113/MC74ACT113 Dual JK Flip-Flop Datasheet
Can the MC74AC112 operate as a D flip-flop?
Yes, by connecting the J and K inputs together.
From: Motorola MC74AC112/MC74ACT112 Dual JK Flip-Flop Datasheet
What happens if both Set and Clear inputs are LOW?
Both Q and Q outputs will be HIGH.
From: Motorola MC74AC112/MC74ACT112 Dual JK Flip-Flop Datasheet
What is the maximum DC supply voltage for the MC74AC11?
The maximum DC supply voltage referenced to GND is +7.0 V.
From: Motorola MC74AC11/MC74ACT11 Triple 3-Input AND Gate Datasheet
What are the available package types for this device?
The device is available in N SUFFIX Plastic DIP (Case 646-06) and D SUFFIX Plastic SOIC (Case 7514-03).
From: Motorola MC74AC11/MC74ACT11 Triple 3-Input AND Gate Datasheet
