MOTOROLA Semiconductor MC6800 user manual
This document serves as an addendum to the M68000 User Manual (Revision 8), containing corrections to the original text and supplementary information. It covers hardware details and programming information for the MC68HC000, MC68HC001, MC68EC000, and MC68SEC000 microprocessors, collectively referred to as M68000 MPUs. The text notes that detailed information on the instruction set can be found in the M68000PM/AD Programmer's Reference Manual.
Read onlineMotorola MC6800 specifications
| Data and Address Registers | Sixteen 32-Bit Data and Address Registers |
|---|---|
| Direct Addressing Range | 16-Mbyte |
| Instruction Types | 6 |
| Data Types | Five Main Data Types |
| Addressing Modes | 14 |
| Typical current consumption (MC68SEC000 sleep mode) | 0.5 mA at 3.3V |
| Typical current consumption (MC68SEC000 normal operation) | 15.0mA at 3.3V |
| Operating Voltage (MC68SEC000) | 3.3V or 5V |
All Motorola MC6800 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the purpose of this document?
This document contains corrections to the original text as well as additional information for the M68000 User Manual.
Which microprocessors are covered in this addendum?
The addendum covers the MC68HC000, MC68HC001, MC68EC000, and MC68SEC000.
What is the power supply requirement for the MC6800?
The device requires only a +5.0-volt power supply and no external TTL devices for bus interface.
How much memory can the MC6800 address?
The microprocessor is capable of addressing 64K bytes of memory.
