Key facts
- Brand
- STMicroelectronics
- Model
- DIL24
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-07
Start here
ST STEVAL-MKI106V1 LSM303DLHC adapter board for a standard DIL24 socket handbook
The STEVAL-MKI106V1 is an adapter board designed to facilitate the evaluation of the LSM303DLHC product family. It offers an effective solution for fast system prototyping and device evaluation directly within the user's own application by plugging into a standard DIL 24 socket.
Read onlineSTMicroelectronics DIL24 specifications
| Socket Type | standard DIL24 socket |
|---|---|
| Compatibility | RoHS compliant |
| Power Supply | decoupling capacitors on the Vpp power supply line |
Source: ST STEVAL-MKI113V1 LSM303DLM adapter board for standard DIL24 socket handbook
All STMicroelectronics DIL24 documents by type
Questions answered in these manuals
What is the STEVAL-MKI106V1 adapter board designed for?
The board is designed to facilitate the evaluation of the LSM303DLHC product family and offers a solution for fast system prototyping.
From: ST STEVAL-MKI106V1 LSM303DLHC adapter board for a standard DIL24 socket handbook
What type of socket is required to use the adapter board?
The adapter board can be plugged into a standard DIL 24 socket.
From: ST STEVAL-MKI106V1 LSM303DLHC adapter board for a standard DIL24 socket handbook
What is the STEVAL-MKI113V1 adapter board designed for?
The board is designed to facilitate the evaluation of the LSM303DLM product family and offers a solution for fast system prototyping.
From: ST STEVAL-MKI113V1 LSM303DLM adapter board for standard DIL24 socket handbook
What standard socket does the adapter board fit into?
The adapter board can be plugged into a standard DIL24 socket.
From: ST STEVAL-MKI113V1 LSM303DLM adapter board for standard DIL24 socket handbook
