STMicroelectronics ST7DALI-EVAL Evaluation Kit Data Brief
The ST7DALI-EVAL is an evaluation kit designed to demonstrate the on-chip lighting control features of the ST7DALI device. It serves as a complete demonstration platform for developers implementing DALI communication interfaces.
The kit consists of one master board featuring a preprogrammed ST72334x microcontroller, two slave boards with preprogrammed ST7DALI microcontrollers, and a software CD-ROM. The system supports networking up to 64 lighting control slave boards and allows testing of various DALI commands via a PC-based interface.
STMicroelectronics ST7DALI-EVAL specifications
| Internal EEPROM | 256 bytes |
|---|---|
| Program memory | 3 Kbytes |
| Flash program memory | 8 Kbytes |
| PWM outputs | 4 |
| I/Os | Up to 15 |
| Clock source | Internal 1% RC oscillator |
| Power consumption (Halt Mode) | 170 mW |
Source: STMicroelectronics AN1900 Application Note Hardware Implementation for ST7DALI-EVAL
All STMicroelectronics ST7DALI-EVAL documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the ST7DALI-EVAL evaluation kit used for?
The kit provides a complete evaluation and demonstration platform for the on-chip lighting control features of the ST7DALI device.
From: STMicroelectronics ST7DALI-EVAL Evaluation Kit Data Brief
How many ST7DALI-based slave boards can be networked with this kit?
The kit allows for networking up to 64 ST7DALI-based lighting control slave boards.
From: STMicroelectronics ST7DALI-EVAL Evaluation Kit Data Brief
What language is the software written in?
The software is written in C language.
From: STMicroelectronics AN1601 Software Implementation for ST7DALI-EVAL Application Note
Which compiler families are supported by this software?
It is compatible with both Metrowerks and Cosmic compilers.
From: STMicroelectronics AN1601 Software Implementation for ST7DALI-EVAL Application Note
What is the purpose of the ST7DALI-EVAL board?
It is an evaluation board that implements a DALI interface in an existing high-frequency dimmable tube-lamp ballast application.
From: STMicroelectronics AN1900 Application Note Hardware Implementation for ST7DALI-EVAL
How does the ST7DALIF2 handle DALI communication?
It uses the DALI Communication Module (DCM) to decode forward frames and send backward frames without CPU overhead.
From: STMicroelectronics AN1900 Application Note Hardware Implementation for ST7DALI-EVAL
