STMicroelectronics uPSD3200 Family Design Guide Application Note AN1560
The document serves as a design guide for the uPSD3200 family, which consists of 8051-class microcontrollers featuring an 8032 core, dual-bank Flash memory, large SRAM, and various peripherals. It focuses on creating designs using the DK3200 development board, the PSDsoft Express software tool, and the uVision2 IDE from Keil Software.
The guide covers the complete design flow, including invoking PSDsoft Express to create projects, defining MCU types and pin configurations, setting up memory maps, and utilizing PLD macrocells for chip-select equations. It also explains how to merge 8032 firmware with UPSD configuration using a utility tool and provides instructions for JTAG programming via the FlashLINK cable.
STMicroelectronics uPSD3200 specifications
| Core Type | 8032 core |
|---|---|
| Max Frequency @ 5.0V | 40MHz |
| Max Frequency @ 3.3V | 24MHz |
| Operating Temperature | Industrial range |
Source: STMicroelectronics uPSD3200 Family Design Guide Application Note AN1560
All STMicroelectronics uPSD3200 documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What software tools are used in this design guide?
The guide uses the DK3200 development board, PSDsoft Express, and uVision2 8051 Integrated Development Environment (IDE) from Keil Software.
From: STMicroelectronics uPSD3200 Family Design Guide Application Note AN1560
What is the maximum operating frequency for the uPSD3200 family?
The device can be clocked up to 40 MHz when powered at 5.0 V.
From: STMicroelectronics uPSD3200 Family Design Guide Application Note AN1560
What is the maximum clock rate of the uPSD3400 MCU core?
The 3400 Turbo MCU core can be clocked up to a maximum rate of 40MHz.
From: STMicroelectronics AN1787 Application Note Conversion Guide uPSD3200 to uPSD3400 Series
How many timer/counter modules does the uPSD3400 have?
The 3400 has a total of nine 16-bit timer/counters, including six in the PCA unit and three standard units.
From: STMicroelectronics AN1787 Application Note Conversion Guide uPSD3200 to uPSD3400 Series
