Start here
STMicroelectronics STP20NE06L/STP20NE06LFP N-Channel MOSFET Datasheet
Datasheet 9 pages · 102 KB · EN
This document is a datasheet for the STP20NE06L and STP20NE06LFP N-channel 60V power MOSFETs. These devices utilize STMicroelectronics' unique Single Feature Size™ strip-based process to achieve low on-resistance and rugged avalanche characteristics. The STP20NE06LFP variant is designed for surface mount applications.
Read onlineAll STMicroelectronics STP20NE06 documents by type
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Is the STP20NE06L avalanche tested?
Yes, the device is 100% avalanche tested.
From: STMicroelectronics STP20NE06L/STP20NE06LFP N-Channel MOSFET Datasheet
What is the maximum junction temperature?
The maximum operating junction temperature is 175 °C.
From: STMicroelectronics STP20NE06L/STP20NE06LFP N-Channel MOSFET Datasheet
