STMicroelectronics AN3404 STM8TL53xx Low Power Application Note
This document provides an overview of low power modes for STM8TL53xx devices, focusing on reducing consumption when using the ProxSense peripheral. It details the differences between various modes and explains how the STM8TL5x Touch Sensing Library manages these features.
Read onlineSTMicroelectronics STM8TL53xx specifications
| Operating voltage range | 1.65 V up to 3.6 V |
|---|---|
| Main voltage regulator current capability | up to 25 mA |
| Low power voltage regulator current capability | up to 200 uA |
Source: STMicroelectronics AN3404 STM8TL53xx Low Power Application Note
All STMicroelectronics STM8TL53xx documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the default clock source after reset?
The default clock source after reset is HSI/8.
From: STMicroelectronics AN3404 STM8TL53xx Low Power Application Note
Which oscillator supplies the auto-wakeup unit and watchdog?
The 38 kHz low-speed internal RC oscillator (LSI) is used to supply the auto-wakeup unit and watchdog.
From: STMicroelectronics AN3404 STM8TL53xx Low Power Application Note
What power supply is required for the STM8TL53xx?
The device requires an external source between 1.65 V and 3.6 V.
From: STMicroelectronics AN3342 Getting Started with STM8TL53xx Application Note
What is the purpose of the ProxSense line management?
It manages the supply voltage needed for the ProxSense interface by connecting a capacitor.
From: STMicroelectronics AN3342 Getting Started with STM8TL53xx Application Note
