Start here
STMicroelectronics STM3210E-EVAL Evaluation Board Data Brief
The STM3210E-EVAL is an evaluation board designed as a complete development platform for STMicroelectronics' ARM Cortex-M3 core-based STM32F103ZET6 or STM32F103ZGT6 microcontroller. The board includes a range of hardware features to help users evaluate various peripherals such as LCD, SPI Flash, USART, IrDA, USB, audio, CAN bus, smartcard, MicroSD Card, NOR Flash, NAND Flash, SRAM, temperature sensor, audio DAC, and motor control.
Read onlineSTMicroelectronics STM3210E-EVAL specifications
| Supported Microcontrollers | STM32F101xC/D/E and STM32F103xC/D/E |
|---|---|
| CPU Core | ARM Cortex-M3 |
| Internal SRAM | 64 Kbyte |
| Flash Memory | 512 Kbyte |
| USB Interface | USB2.0 full speed |
| LCD Display | 240 x 320 TFT color LCD |
Source: STMicroelectronics AN3012 uClinux for STM32F10x High-Density Devices Application Note
All STMicroelectronics STM3210E-EVAL documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What microcontroller does this evaluation board support?
The board is designed for the STM32F103ZET6 or STM32F103ZGT6 microcontroller.
From: STMicroelectronics STM3210E-EVAL Evaluation Board Data Brief
What are the three power supply options for this board?
The board supports power via a power jack, a USB connector, or a daughterboard.
From: STMicroelectronics STM3210E-EVAL Evaluation Board Data Brief
What is the purpose of this application note?
The purpose is to explain how to install the uClinux operating system, toolchain, and configure the kernel for the STM3210E-EVAL board.
From: STMicroelectronics AN3012 uClinux for STM32F10x High-Density Devices Application Note
Which board is supported by this guide?
This guide supports the STM3210E-EVAL evaluation board.
From: STMicroelectronics AN3012 uClinux for STM32F10x High-Density Devices Application Note
