STMicroelectronics AN4055 STM32F0xx Clock Configuration Tool Application Note
This document presents a clock configuration tool designed for the STM32F0xx microcontroller family. The tool assists users in configuring the microcontroller's clock system by considering specific product parameters such as power supply requirements and Flash access modes. It is implemented as an Excel file named STM32F0xx_Clock_Configuration_VX.Y.Z.xls.
Read onlineSTMicroelectronics STM32F0xx specifications
| Supported Microcontroller Family | STM32F0xx |
|---|---|
| Minimum RAM Requirement | 256 Mbytes |
| Clock Sources | HSI, HSE, PLL |
| Flash Latency Rule | Zero wait states if 0 < SYSCLK <= 24 MHz |
Source: STMicroelectronics AN4055 STM32F0xx Clock Configuration Tool Application Note
All STMicroelectronics STM32F0xx documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the purpose of the clock configuration tool?
The purpose of this tool is to help the user configure the microcontroller clocks, taking into consideration product parameters such as power supply and Flash access mode.
From: STMicroelectronics AN4055 STM32F0xx Clock Configuration Tool Application Note
What operating systems are supported for the clock tool?
The tool requires a Windows operating system, such as Windows XP, Vista, or Windows 7.
From: STMicroelectronics AN4055 STM32F0xx Clock Configuration Tool Application Note
What are the supported data formats for the STM32 DAC?
The DAC accepts data in three integer formats: 8-bit, 12-bit right aligned, and 12-bit left aligned.
From: STMicroelectronics AN4058 STM32F0xx DAC Audio and Waveform Generation Application Note
Can the STM32 DAC drive external loads without an operational amplifier?
Yes, by enabling the embedded output buffer on the DAC channel.
From: STMicroelectronics AN4058 STM32F0xx DAC Audio and Waveform Generation Application Note
What protocol is used for data transfer in the IAP driver?
The YMODEM protocol is used to receive/send data from/to the HyperTerminal application.
From: STMicroelectronics AN4065 STM32F0xx In-Application Programming Application Note
How does the user switch between the user application and IAP mode?
The user can press a push-button connected to a specific pin at reset; not pressing it switches to the user application.
From: STMicroelectronics AN4065 STM32F0xx In-Application Programming Application Note
