Key facts
- Brand
- STMicroelectronics
- Model
- ST7FLITE05
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-07
Start here
STMicroelectronics AN1827 Sigma-Delta ADC Implementation Application Note
This document details the implementation of a 10-bit Sigma-Delta Analog-to-Digital Converter (ADC) using the ST7FLITE05/09 microcontroller. The solution is designed for relatively slow alternating signals (0.2 - 5Hz) in the range of 0 - 10mV peak-to-peak. The approach utilizes a simple external circuit consisting of only three RC elements alongside the microcontroller to achieve good relative accuracy and low cost.
Read onlineSTMicroelectronics ST7FLITE05 specifications
| Resolution | 10-bit |
|---|---|
| Input Range | 0 - 10mV(p-p) |
| Signal Frequency | 0.2 - 5Hz |
| Conversion Period | 51.2ms |
| Interrupt Period | 50us |
| External Components | three RC elements |
Source: STMicroelectronics AN1827 Sigma-Delta ADC Implementation Application Note
All STMicroelectronics ST7FLITE05 documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the purpose of this document?
To describe how to implement a 10-bit Sigma-Delta A/D converter using a simple external circuit and a Sigma-Delta conversion program.
From: STMicroelectronics AN1827 Sigma-Delta ADC Implementation Application Note
What type of signals is this converter designed for?
It is designed for relatively slow alternating signals between 0.2 and 5Hz with a voltage range of 0 to 10mV peak-to-peak.
From: STMicroelectronics AN1827 Sigma-Delta ADC Implementation Application Note
Which microcontrollers are supported for this PIR detector design?
The design supports the ST7FLITE05(09) and Superlite microcontroller families.
From: STMicroelectronics AN1828 Application Note PIR Detector using ST7FLITE05/09/Superlite
How is sensitivity adjusted in this system?
Sensitivity can be changed by assigning high or small values to parameters in the 'select_sensitivity()' function within main.c.
From: STMicroelectronics AN1828 Application Note PIR Detector using ST7FLITE05/09/Superlite
