Key facts
- Brand
- STMicroelectronics
- Model
- DEMO-CR95HF-A
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-07
Start here
STMicroelectronics DEMO-CR95HF-A Data Brief
The DEMO-CR95HF-A is a ready-to-use printed circuit board designed to evaluate the performance of the ST CR95HF 13.56 MHz multiprotocol contactless transceiver IC. The kit includes an etched antenna, tuning components, and associated firmware for communication with a host PC via USB.
Read onlineAll STMicroelectronics DEMO-CR95HF-A documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the DEMO-CR95HF-A?
It is a demonstration kit for the CR95HF 13.56 MHz transceiver IC.
Does the board require an external power supply?
No, the board is powered through the USB bus and no external power supply is required.
What programming languages are supported for developing applications on the DEMO-CR95HF-A?
The application note explains how to develop an application using either Visual Basic or C/C++ language.
From: STMicroelectronics AN3954 Application Note for DEMO-CR95HF-A Board
Is a separate power supply required for the DEMO-CR95HF-A board?
No, the board is powered through the USB port and no external power supply is required.
From: STMicroelectronics AN3954 Application Note for DEMO-CR95HF-A Board
