The MC6800 is a monolithic 8-bit microprocessor forming the central control function for Motorola's M6800 family. Compatible with TTL, the MC6800, as with all M6800 system parts, requires only one + 5.O-volt power supply, and no external TTL devices for bus interface. The MC6800 is capable of addressing 64K bytes of memory with its 16-bit address lines. The 8-bit data bus is bidirectional as well as three- state, making direct memory addressing and multiprocessing applica- tions realizable.
This document provides comprehensive technical specifications for the Motorola MC6800 monolithic 8-bit microprocessing unit (MPU). It describes the device's capabilities, including its compatibility with TTL logic, +5.0-volt power supply requirements, and ability to address 64K bytes of memory using a 16-bit address bus.
The datasheet details key features such as 72 instructions, seven addressing modes, vectored restarts, and maskable interrupt vectors. It also includes maximum ratings, DC electrical characteristics, clock timing parameters, and package type information for various order numbers.
| Data Bus Width | 8-bit |
|---|---|
| Address Bus Width | 16-bit |
| Memory Addressing Capacity | 64K bytes |
| Number of Instructions | 72 |
| Addressing Modes | Seven |
| Power Supply Voltage | +5.0 volts |
| Maximum Clock Rate (MC68B00) | 2.0 MHz |
The device requires only a +5.0-volt power supply and no external TTL devices for bus interface.
The microprocessor is capable of addressing 64K bytes of memory.
The plastic package can be stored between -55°C and +150°C.
