IXYS IXGH40N30A IGBT Preliminary Data Sheet
Datasheet 2 pages · 33 KB · EN
This document provides preliminary data for the IXYS IXGH40N30A, a HiPerFAST™ IGBT available in the JEDEC TO-247 AD package. Key features include high current handling capability, MOS gate turn-on drive simplicity, and suitability for surface mounting.
Read onlineAll IXYS IXGH40N30A documents by type
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Other documents 1
Questions answered in these manuals
What are the applications for the IXGH40N30A?
It is suitable for AC motor speed control, DC servo and robot drives, DC choppers, and various power supplies.
What are the minimum and maximum dimensions for the mounting hole distance from the case?
The dimension for the lead temperature limit is specified as 1.6 mm (0.062 in.) from the case.
