Toshiba TC7SHU04FS Inverter (Un-Buffer) Datasheet
The TC7SHU04FS is a CMOS digital integrated circuit designed as an inverter (un‑buffer). It offers high speed with a typical propagation delay of 3.5 ns and low power dissipation of 2 µA max. The device operates over a wide supply voltage range (‑0.5 V to 7.0 V) and supports 5.5 V tolerant inputs.
The datasheet lists absolute maximum ratings, detailed DC and AC electrical characteristics, package dimensions, and important restrictions on product use. It also includes handling and reliability guidance for designers to ensure safe and reliable system integration.
Toshiba TC7SHU04FS specifications
| Typical propagation delay (tpg) | 3.5 ns |
|---|---|
| Maximum supply current (Icc) | 2 µA |
| Supply voltage range (Voc) | -0.5 V to 7.0 V |
| Input voltage range (VIN) | -0.5 V to 7.0 V |
| Power dissipation (Pp) | 50 mW |
| Storage temperature (Tstg) | -65 °C to 150 °C |
| Operating temperature (Topr) | -40 °C to 85 °C |
| Package weight | 0.001 g (typ.) |
All Toshiba TC7SHU04FS documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the typical propagation delay of the TC7SHU04FS?
The typical propagation delay (tpg) is 3.5 ns.
What is the maximum supply current for the device?
The maximum supply current (Icc) is 2 µA.
What is the maximum supply voltage for the TC7SHU04FS?
The device can be powered from –0.5 V up to 7.0 V.
What temperature range is recommended for operating the TC7SHU04FS?
It is specified to operate between –40 °C and 85 °C.
