TOSHIBA TLSU1102A(T02)/TLOU1102A(T02)/TLYU1102A(T02)/TLGU1102A(T02)/TLPGU1102A(T02) Manual(1)
The TLSU1002A series comprises surface‑mount LED lamps in six color variants (Red, Orange, Amber, Yellow, Green, Pure‑Green) intended for backlighting, pilot lights and low‑power electronic equipment. The devices are packaged on 1.25 × 1.1 mm panels and are suitable for solder reflow processes.
Key electrical parameters include a forward voltage of about 2.0‑2.5 V and a forward current of 60 mA. Optical data provide luminous intensities ranging from ~27 cd to ~85 cd depending on color. Devices are supplied on reels of 8 000 units, packed with silica gel in sealed aluminum packs, and shipped in cartons of up to 15 000 units.
Toshiba TLSU1102A specifications
| Forward Voltage (typical) | 2.0‑2.5 V |
|---|---|
| Forward Current | 60 mA |
| Luminous Intensity (typical) | 27.2‑85 cd |
| Package Size | 1.25 × 1.1 mm |
| Devices per Reel | 8 000 |
| Devices per Carton | 15 000 |
Source: TOSHIBA TLSU1102A(T02)/TLOU1102A(T02)/TLYU1102A(T02)/TLGU1102A(T02)/TLPGU1102A(T02) Manual(1)
All Toshiba TLSU1102A documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the forward voltage range of the TLSU1002A series?
The typical forward voltage is between 2.0 V and 2.5 V.
From: TOSHIBA TLSU1102A(T02)/TLOU1102A(T02)/TLYU1102A(T02)/TLGU1102A(T02)/TLPGU1102A(T02) Manual(1)
How many devices are packed on each reel?
Each reel contains 8 000 devices.
From: TOSHIBA TLSU1102A(T02)/TLOU1102A(T02)/TLYU1102A(T02)/TLGU1102A(T02)/TLPGU1102A(T02) Manual(1)
What is the maximum forward current for the TLSU1002A series?
The TLSU1002A device is rated for a maximum forward current of 60 mA; other variants are rated at 62.5 mA.
From: TOSHIBA TLSU1102A(T02)/TLOU1102A(T02)/TLYU1102A(T02)/TLGU1102A(T02)/TLPGU1102A(T02) Manual
Which colors are offered for these LED lamps?
The series is available in Red, Orange, Amber, Yellow, Green, and Pure‑Green.
From: TOSHIBA TLSU1102A(T02)/TLOU1102A(T02)/TLYU1102A(T02)/TLGU1102A(T02)/TLPGU1102A(T02) Manual
