Key facts
- Brand
- STMicroelectronics
- Model
- STM8SVLDISCOVERY
- Category
- microcontrollers
- Documents
- 3
- Languages
- EN
- Last added
- 2012-08-07
Start here
STMicroelectronics STM8SVLDISCOVERY Evaluation Board Data Brief
The STM8SVLDISCOVERY is a quick start evaluation board designed to help users discover the features of the STM8S Value line microcontrollers and develop their own applications. It is built around the STM8S003K3T6 microcontroller, which includes 8 KB of Flash, 1 KB of RAM, and 128 bytes of EEPROM. The board allows for the evaluation of main features across the entire STM8S Value line family.
Read onlineSTMicroelectronics STM8SVLDISCOVERY specifications
| Microcontroller | STM8S003K3T6 |
|---|---|
| Flash Memory | 8 KB |
| RAM | 1 KB |
| EEPROM | 128 bytes |
| Debug Interface | Embedded ST-LINK |
| Power Supply | 5 V or 3.3 V |
Source: STMicroelectronics STM8SVLDISCOVERY Evaluation Board Data Brief
All STMicroelectronics STM8SVLDISCOVERY documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the purpose of the STM8SVLDISCOVERY?
It is a quick start evaluation board that helps users discover STM8S Value line features and develop applications.
From: STMicroelectronics STM8SVLDISCOVERY Evaluation Board Data Brief
What development tools are required?
Required tools include IAR Embedded Workbench for STM8, ST Visual Programmer (STVP), and ST Visual Develop (STVD).
From: STMicroelectronics STM8SVLDISCOVERY Evaluation Board Data Brief
What hardware is required to run this application?
The application requires an STM8SVLDISCOVERY board, a 10 K potentiometer, 4 LEDs, and 4 resistors of 510 ohms.
From: STMicroelectronics AN4014 Adjustable LED Blinking Frequency Application Note
How is the blinking frequency controlled?
The blinking frequency is controlled by a potentiometer which adjusts the analog voltage measured by the ADC, thereby changing the delay time for each LED.
From: STMicroelectronics AN4014 Adjustable LED Blinking Frequency Application Note
What happens when the push button B1 is pressed?
Each time the push button event is detected, the delay between LED toggles is adjusted to change the blinking frequency.
From: STMicroelectronics AN3996 Adjustable LED Blinking Speed Application Note
What are the LED blinking periods for each button press?
The first press sets a 200 ms period, the second press sets a 100 ms period, and the third press switches the LED off.
From: STMicroelectronics AN3996 Adjustable LED Blinking Speed Application Note
