Start here
STMicroelectronics STM32L-DISCOVERY Data Brief
The STM32L-DISCOVERY is an ultralow power discovery board based on the STM32L152RBT6 microcontroller. It features 128 KB Flash, 16 KB RAM, and 4 KB EEPROM in an LQFP64 package. The board includes an on-board ST-Link/V2 debugging tool and supports power supply via USB or external 3.3V/5V sources.
Read onlineSTMicroelectronics STM32L-DISCOVERY specifications
| Microcontroller | STM32L152RBT6 |
|---|---|
| Flash Memory | 128 KB |
| RAM | 16 KB |
| EEPROM | 4 KB |
| Package | LQFP64 |
| LCD | 24 segments, 4 commons |
| Power Supply | USB bus or external 3.3 or 5 V |
All STMicroelectronics STM32L-DISCOVERY documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the purpose of the STM32L-DISCOVERY?
It helps you to discover the STM32L ultralow power features and to develop and share your applications.
What operating systems are supported?
Windows PC (2000, XP, Vista, 7).
What hardware components are used in the demonstration?
The application uses the hardware components available on the STM32L-DISCOVERY board, including on-board LEDs, a 6-digit/4-bar LCD glass display, a user push-button, and a touch sense slider.
From: STMicroelectronics AN3413 STM32L-DISCOVERY Application Note
How do you access the manufacturing test mode?
While in Demo mode, press and hold the USER push-button for more than 3 seconds, then release it to verify that the hardware modules are working properly.
From: STMicroelectronics AN3413 STM32L-DISCOVERY Application Note
